مشخصات بيشتر
چاپگر EPSON
TM-U950
(بر گرفته از سايت-EPSON)
This high-performance 2.5 station model in the TM
Series will meet your multifunction needs for large POS systems.
|
Versatility and dependability make theTM-U950
the perfect choice for large POS systems used by mass merchandisers and other
large stores.
Advanced paper handling
The multifunctional
TM-U950 handles a variety of printing
formats including receipts, journals, and wide slips.
When it comes to slip printing, the
EPSON
TM-U950 will print an original and up to four duplicates.
High performance
With print speeds exceeding 300characters per second, and the unique ability to
print 88columns, the
TM-U950 quickly gets the customers through
the checkout line. Add MICR capability and the
TM-U950 becomes an ideal candidate for
retail and mass merchandiser applications.
Reliability
EPSON’s world-renowned quality and reliability are reflected in
every component and mechanism of the
TM-U950, ensuring products unsurpassed in
performance and dependability. |
•High performance
•Versatile and fast, wide slip printer
•Flexible paper handling
•NT & IT service connectivity
•ESC/POS & OPOS
|
|
User-friendly design
The drop-in semi-automatic paper loading system and two paper sensors reduce
reloading time.
Incombination with an
EPSON Intelligent Module, the
TM-U950 printer offers an unparalleled
selection of business applications.
Add an ASB (Automatic Status Back) function to keep operators constantly
informed of printer status.
|
|
| Print Method |
9-pin, serial impact dot matrix |
| Print Font |
7 × 9 / 9 × 9 |
| Column capacity |
Receipt (Journal): 40 / 30 columns
Slip: 88 / 66 columns |
| Character size |
1.3 × 3.1 mm (W × H) / 1.6 × 3.1 mm (W × H) {0.05 × 0.12" / 0.06 × 0.12"} |
| Character set |
95 Alphanumeric characters,
32 International characters,
128 × 8 Graphic characters |
| Characters per 25.4mm |
16.7 cpi / 12.5 cpi |
| Print Speed |
311 cps / 233 cps |
| Data Buffer |
2KB or 32 bytes |
| Interfaces |
RS-232C / Bi-directional parallel |
| Paper Dimensions |
Receipt (Journal): roll paper 69.5 ± 0.5 (W) × diameter 83.0 mm {2.73 ± 0.02
× diameter 3.27"}
Slip: 70 to 210 × 70 to 297 mm (W × L) {2.76 to 8.27 × 2.76 to 11.69"} |
| Paper Thickness |
Receipt (Journal): 0.06 to 0.09 mm {0.0024 to
0.0035"}
Slip: 0.09 to 0.36 mm {0.0035 to 0.0142"},
Validation: 0.09 to 0.2 mm {0.0035 to 0.0079"} |
| Copy Capability |
One original and four copies (for slip) |
| Inked Ribbon |
ERC-31 (purple, black) |
| Ribbon Life |
7,000,000 characters (purple), 4,500,000 characters (black) |
| Power |
24 VDC ± 10% |
| Current Consumption |
Approx. 1.8A (at VDC) |
| D.K.D. Function |
2 drivers |
| Reliability |
MTBF180,000 hours
MCBF18,000,000 lines |
| Overall Dimensions |
251 × 298 × 194.5 mm (W × D × H) {9.9 × 11.7 × 7.7"} (TM-U950)
251 × 298 × 193.7 mm (W × D × H) {9.9 × 11.7 × 7.6"} (TM-U925) |
| Mass |
Approx. 5.6 kg {12.3 lb} |
| EMI Standards |
VCCI class A, FCC class A, CE marking |
| Safety Standards |
UL, CSA |
| |
|
Inch values are approximate.
cpi: characters per 25.4 mm (characters per inch)
cps: characters per second |
|
|
|
